产品展示   产品名称：JSF12025 产品型号：120X120X25 产品说明： MODEL NO RATED VOLTAGE V OPERATING VOLTAGE V RATED CURRENT A ACTUAL CURRENT A RATED POWER W RATED SPEED RPM MAX. AIR FLOW MAX. STATIC AIR PRESSURE NOISE LEVEL dBA CMM CFM mmH2O InH2O 12025TL12S/B/F- 12 8~13.8 0.10 0.07 1.20 1200 1.436 50.72 0.98 0.039 23.9 12025LL12S/B/F- 12 8~13.8 0.18 0.14 2.16 1600 1.897 67.01 1.63 0.064 31.4 12025L12S/B/F 12 6~13.8 0.40 0.27 4.80 2000 2.425 85.64 2.43 0.096 37.2 12025M12S/B/F- 12 6~13.8 0.60 0.45 7.20 2400 2.940 103.82 3.50 0.138 42.5 12025H12S/B/F- 12 6~13.8 0.80 0.75 9.60 2800 3.395 119.90 4.93 0.194 47.5 12025HH12S/B/F- 12 6~13.8 1.20 1.05 14.40 3200 4.125 145.69 6.17 0.243 51.4 12025L24S/B/F- 24 12~27.6 0.20 0.17 4.80 2000 2.425 85.64 2.43 0.096 37.2 12025M24S/B/F- 24 12~27.6 0.30 0.19 7.20 2400 2.940 103.82 3.50 0.138 42.5 12025H24S/B/F- 24 12~27.6 0.40 0.34 9.60 2800 3.395 119.90 4.93 0.194 47.5 12025L48S/B/F- 48 24~52.8 0.15 0.10 7.20 2000 2.425 85.64 2.43 0.096 37.2 12025M48S/B/F- 48 24~52.8 0.20 0.13 9.60 2400 2.940 103.82 3.50 0.138 42.5 12025H48S/B/F- 48 24~52.8 0.25 0.18 12.00 2800 3.395 119.90 4.93 0.194 47.5
